Virtually the same as the 1934 model, except for a new bumper. The designation changed to Series 40.
Series 40 Fleetwood 146 in. Wheelbase Vee Windshield | ||||
---|---|---|---|---|
Style Number | Style | Seating | Price | Weight |
5702 | Roadster | 2 | ||
5712-C | Collapsible Town Cabriolet | 5 | ||
5712-LB | Town Cabriolet | 5 | $6195 | 2723 kg |
5712-MB | Town Cabriolet | 5 | ||
5720 | Town Cabriolet | 7 | ||
5720-C | Collapsible Town Cabriolet | 7 | ||
5725-B | Town Cabriolet | 7 | ||
5725-LB | Town Cabriolet | 7 | $6295 | 2745 kg |
5725-MB | Town Cabriolet | 7 | ||
5730 | Imperial Sedan | 5 | ||
5730-FL | Imperial Cabriolet | 5 | $4845 | 2620 kg |
5730-FM | Imperial Brougham | 5 | ||
5730-S | Sedan | 5 | $4445 | 2607 kg |
5733 | Imperial Town Sedan | 5 | ||
5733-S | Town Sedan | 5 | $4995 | 2591 kg |
5735 | Convertible Coupe | 2 | $4745 | 2493 kg |
5757 | Transformable | 7 | ||
5759 | Sport Phaeton | 5 | ||
5775 | Imperial Sedan (Limousine) | 7 | $4795 | 2632 kg |
5775-B | Limousine | 7 | ||
5775-E | Imperial Sedan | 7 | ||
5775-FL | Imperial Cabriolet | 7 | $4995 | 2632 kg |
5775-FM | Imperial Brougham | 7 | ||
5775-H4 | Imperial Sedan | 7 | ||
5775-S | Sedan | 7 | $4595 | 2618 kg |
5775-W | Limousine | 7 | ||
5776 | Coupe | 2 | $4595 | 2509 kg |
5780 | Convertible Sedan with divider | 5 | $4995 | 2636 kg |
5780-B | Convertible Sedan | 5 | ||
5780-S | Convertible Sedan | 5 | 2623 kg | |
5785 | Collapsible Coupe | 5 | $4995 | 2584 kg |
5788 | Stat. Coupe | 5 | 2600 kg | |
5789-A | Victoria Coupe | 4 | ||
5791 | Limousine Brougham | 7 | $6195 | 2741 kg |
5791-B | Limousine Brougham | 7 | ||
5799 | Aero. Coupe | 5 | $4995 | 2600 kg |
Some listings show these as 61___ styles. | ||||
---|---|---|---|---|
Series 40 Fleetwood 146 in. Wheelbase Flat Windshield | ||||
Style Number | Style | Seating | Price | Weight |
6030-8 | Imperial Sedan | 5 | ||
6030-FL | Imperial Cabriolet | 5 | $4395 | 2620 kg |
6030-FM | Imperial Brougham | 5 | ||
6030-S | Sedan | 5 | $3995 | 2607 kg |
6033-S | Town Sedan | 5 | $4045 | 2591 kg |
6035 | Convertible Coupe | 2 | ||
6075 | Imperial Sedan | 7 | $4345 | 2632 kg |
6075-B | Limousine (spec. back) | 7 | ||
6075-D | Limousine | 7 | ||
6075-E | Limousine | 7 | ||
6075-FL | Imperial Cabriolet | 7 | $4545 | 2632 kg |
6075-FM | Imperial Brougham | 7 | ||
6075-H3 | Limousine | 7 | ||
6075-H4 | Limousine | 7 | ||
6075-0 | Imperial Sedan | 7 | ||
6075-S | Sedan | 7 | $4145 | 2618 kg |
Type | 45 degree, overhead valve |
Cylinders | Twelve cylinders. |
Crankcase | Cast iron block on aluminum crankcase. |
Bore & Stroke | 79.4mm x 101.6mm |
Displacement | 6.035 Liters |
Compression Ratio | 6.00:1 std. 5.65:1 opt. |
Brake Horsepower | 150 hp @ 3600 rpm |
Power | 112 kW @ 3600 rpm |
SAE/Taxable Horsepower | 46.9 |
Main bearings | Four |
Valve lifters | Mechanical with hydraulic silencer on rocker bushings |
Carburetor | Dual Detroit lubricator, Type R-13, L-13, model 51. |
Feature | Series 10 | Series 20 | Series 30 | Commercial |
---|---|---|---|---|
Wheelbase | 3251mm | 3454mm | 3708mm | 4064mm |
Overall length | 5271mm | 5470mm | 5780mm | |
Front/Rear Tread | 1508mm | 1508mm | 1508mm | |
Rear Tread | 1575mm | 1575mm | 1575mm | |
Tires | 7.00 x 17 | 7.00 x 17 | 7.00 x 17 |
Transmission | Selective, synchro transmission. |
Speeds | 3 Forward 1 Reverse |
Control | Left Hand Drive, Center control, emergency brake lever at left -- under panel (rhd opt). |
Clutch | Twin disc clutch. |
Drive | Shaft drive, Hotchkiss. |
Axle | 3/4 floating rear axle |
Drive Type | spiral bevel drive. |
Overall ratio | 4.80:1 std., 4.60:1 opt., 5.11:1 opt. |
Brakes | Mechanical brakes with vacuum assist on four wheels. |
Wheels | Wire wheels. |
Wheel size | 17 in. drop center. |
