Since the Stingray front fender nameplate departed this year, Chevrolet's sports car technically no longer had a secondary title.
- Changes were fairly modest this year and mainly hidden (such as a steel hood reinforcement) or inside.
- New crossed-flags emblems stood between the headlamps and on the fuel filler door.
- A thinner blacked-out pillar gave the windshield and side glass a more integrated look.
- The Corvette's console was restyled in an aircraft-type cluster design, with individual-look gauges.
- A voltmeter replaced the former ammeter.
- "Door ajar" and "headlamp up" warning lights were abandoned.
- New heater/air conditioning controls, an ashtray, and a lighter were on the horizontal surface.
- A recessed pocket was now seen behind the shift lever.
- Power window switches moved to the new console.
- The manual shift lever was almost an inch higher, with shorter travel.
- Automatic transmission levers added a pointer and both manual and automatic shifters added a new black leather boot.
- A shorter steering column held a multi-function control lever.
- This year's steering wheel had a leather-wrapped rim.
- This year's colors were
- Classic White
- Silver
- Black
- Corvette Light Blue
- Corvette Dark Blue
- Corvette Chartreuse (used on one car)
- Corvette Yellow
- Corvette Orange
- Medium Red
- Corvette Tan
- Corvette Dark Red
- The Custom interior, formerly an extra-cost option, was now standard.
- "Dynasty" horizontal-ribbed cloth upholstery was framed with leather (the first cloth trim offered on a Corvette), or buyers could have the customary all-leather seat panels.
- Leather came in ten colors, cloth in six.
- Two new trim colors were available: Red and Blue.
- Door panel inserts were satin finish Black instead of the prior wood grain.
- Both the instrument panel and door trim panels lost their embossed stitch lines.
- New padded sunshades could swivel to side windows.
- Passenger-side roof pillars held a soft vinyl coat hook.
- Power trains were the same as in 1976, but power brakes and steering were now standard.
- A total of 6,148 Corvettes came with the special L82 V-8 engine under the hood, while 7,269 had the optional Gymkhana suspension.
- Only 5,743 Corvettes had the M20 four-speed manual gearbox and 2,060 used the M26 close-ratio four-speed.
- A mere 289 Corvettes came with trailering equipment.
- New options included an AM/FM stereo radio with tape player, cruise control (for cars with automatic transmission only), and a luggage carrier that could hold the roof panels.
- Glass roof panels were announced, but delayed for another year.
V.I.N. NUMBERS
- The serial number [Vehicle Identification Number -- VIN] was stamped on a plate on the inner vertical surface of the left windshield pillar visible through the windshield.
- Serial numbers ranged from 1Z37*7S400001 to 1Z37*7S449213
Position |
Character |
Description |
1 |
1 |
Chevrolet Division |
2 |
Z |
Corvette |
3&4 |
37 |
coupe |
5 |
* |
Engine type where * is replaced by the following
- L = L48 350-cid V8, 180-hp, 4-barrel
- X = L82 350-cid V8, 210-hp, 4-barrel
|
6 |
7 |
1977 |
7 |
S |
Assembled in St. Louis, MO |
8 to 13 |
400001 to 446558 |
production sequence |
- Engine serial number began 0001001
- Corvette engines have the last six digits of the VIN stamped on the block just ahead of the cylinder head on the right-hand side combined with a three-letter engine code suffix
- Also cast into the top rear of the block is a four-symbol code indicating when the engine was built
- The first letter of the date code shows the month the block was cast
- The one or two numbers shows the month
- The last digit shows the year
- Engine suffixes:
Code |
Engine |
Horsepower |
Compression |
Transmission |
Fuel Supply |
Emission Control System |
CHD |
350-cid |
180-hp V-8 |
8.5:1 |
automatic |
four-barrel carburetor |
California |
CKD |
350-cid |
180-hp V-8 |
8.5:1 |
automatic |
four-barrel carburetor |
high-altitude |
CKZ |
350-cid |
180-hp V-8 |
8.5:1 |
manual |
four-barrel carburetor |
|
CLA |
350-cid |
180-hp V-8 |
8.5:1 |
automatic |
four-barrel carburetor |
|
CLB |
350-cid |
180-hp V-8 |
8.5:1 |
automatic |
four-barrel carburetor |
high-altitude |
CLC |
350-cid |
180-hp V-8 |
8.5:1 |
automatic |
four-barrel carburetor |
California |
CLD |
350-cid |
210-hp V-8 |
9.0:1 |
manual |
four-barrel carburetor |
|
CLF |
350-cid |
210-hp V-8 |
9.0:1 |
automatic |
four-barrel carburetor |
|
- The body number plate was located on the engine side of the cowl.
- The Fisher Body Style Number 77-1YZ37 identifies a Corvette Stingray coupe
- The body number is the production serial number of the body.
- The trim number indicates the interior trim color and material.
- The eleven 1977 Corvette exterior colors were:
- 10 = Classic White
- 13 = Silver
- 19 = Black
- 26 = Corvette Light Blue
- 28 = Corvette Dark Blue
- 41 = Corvette Chartreuse (used on one car)
- 52 = Corvette Yellow
- 66 = Corvette Orange
- 72 = Medium Red
- 80 = Corvette Tan
- 83 = Corvette Dark Red
- Upholstery Codes
Color |
Cloth & Leather Upholstery |
Leather Upholstery |
Black |
19C |
192 |
Smoked Gray |
15C |
152 |
Blue |
27C |
|
Brown |
69C |
692 |
Red |
72C |
722 |
Buckskin |
|
642 |
White |
|
112 |
IDENTIFICATION
Model No. |
Body/Style No. |
Body Type |
Factory Price |
Shipping Weight |
Production Total |
1Y |
Z37 |
2-dr. Sport Coupe - 2 passenger
|
$8648 |
3448 |
49,213 |
ENGINE
Feature |
Standard Engine (RPO L48) |
Optional Engine (RPO L82) |
Type | V-8, Overhead valve |
Block | Cast iron block |
Displacement |
350 cid (5.7 liters) |
350 cid (5.7 liters) |
Bore & Stroke |
4.00 x 3.48" |
4.00 x 3.48" |
Compression ratio |
8.5:1 |
9.0:1 |
Brake horsepower |
180 @ 4000 |
210 @ 5200 |
Torque |
270 lb-ft @ 2400 |
255 lb-ft @ 3600 |
Main bearing | five |
Valve lifters | hydraulic |
Fuel supply |
Rochester M4MC |
Rochester M4MC |
TRANSMISSION
- Manual transmission
- four-speed fully-synchronized
- floor-mounted gear shifter
- gear ratios
- 1st = 2.64:1
- 2nd = 1.75:1
- 3rd = 1.34:1
- 4th = 1.00:1
- Rev = 2.55:1
- Final drive ratio: 3.36:1
- Optional Manual Transmission
- close ratio four-speed fully-synchronized
- floor-mounted gear shifter
- gear ratios
- 1st = 2.43:1
- 2nd = 1.61:1
- 3rd = 1.23:1
- 4th = 1.00:1
- Rev = 2.35:1
- Final drive ratio: 3.36:1
- Automatic Transmission
- Three-speed Turbo Hydra-Matic
- floor-mounted gear shifter
- gear ratios
- 1st = 2.48:1
- 2nd = 1.48:1
- 3rd = 1.00:1
- Rev = 2.08:1
- Final drive ratio: 3.36:1
CHASSIS
Feature |
Coupe |
Wheelbase |
98 inches (2.489 m) |
Overall length |
185.2 inches (4.704 m) |
Overall width |
69.0 inches (1.753 m) |
Overall height |
48 inches (1.219 m) |
Ground Clearance |
4.5 inches (11.4 cm) |
Front tread |
58.7 inches (1.491 m) |
Rear tread |
59.5 inches (1.511 m) |
Tires |
GR70 x 15 |
Positraction |
standard |
Steering |
recirculating ball |
Front suspension |
Independent, unequal-length control arms with ball joints, coil springs, and stabilizer bar |
Rear suspension |
Independent, trailing link, transverse semi-elliptic leaf springs |
Brakes |
Hydraulic, vented four wheel discs; 11.75-inch diameter, single calipers |
Ignition |
HEI electronic |
Body construction |
Separate fiberglass body and box-type ladder frame with cross-members |
Fuel tank |
17 US Gal (14 Imp Gal) (64 liters) |
OPTIONS
RPO A31 |
Electric power windows |
$116 |
RPO B32 |
Color-keyed floor mats |
$22 |
RPO C49 |
Rear window defogger |
$84 |
RPO C60 |
Air conditioning |
$553 |
RPO D35 |
Sport mirrors |
$36 |
RPO FE7 |
Gymkhana suspension |
$38 |
RPO L82 |
350-cid 210-hp V-8 |
$495 |
RPO M21 |
Four-speed close-ratio manual transmission |
no-cost option |
RPO M40 |
Turbo Hydra-Matic automatic transmission |
no-cost option |
RPO N37 |
Tilt-telescopic steering wheel |
$165 |
RPO N40 |
Power steering |
$151 |
RPO QRZ |
GR7O x 15 raised-white-letter steel-belted radial tires |
$57 |
RPO U58 |
AM-FM stereo radio |
$187 |
RPO UM2 |
AM-FM stereo radio with tape system |
$414 |
RPO U69 |
AM-FM radio |
$187 |
RPO V54 |
Luggage rack and roof panel rack |
$73 |
RPO YJ8 |
Aluminum wheels |
$321 |
RPO ZN1 |
Trailering package |
$83 |
RPO ZX2 |
Convenience group |
$22 |
