The eagerly-awaited sixth-generation Corvette for the '80s missed the 1983 model year completely, but arrived in spring 1983 in an all-new form.
- An aerodynamic exterior featuring an "acute" windshield rake (64 degrees) covered a series of engineering improvements.
- A one-piece, full-width fiberglass roof (no T-bar) was removable.
- It had a transparent, acrylic lift-off panel with a solar screen optional.
- At the rear was a frameless glass back window or hatch above four round tail lamps.
- Hidden headlamps were featured, along with clear, integrated halogen fog lamps and front cornering lamps.
- The dual sport mirrors were electrically remote controlled.
- The unit body (with partial front frame) used a front-hinged "clam shell" hood with integral twin-duct air intake.
- The sole 1984 V-8 was L83 350-cid (5.7-liter) V-8 with cross-fire fuel injection.
- Stainless steel headers led into its exhaust system.
- The air cleaner and the valve train had cast magnesium covers.
- After being unavailable in 1982, a four-speed manual gearbox returned as the standard Corvette transmission (although not until January 1984).
- A four-plus-three-speed automatic with computer-activated overdrive in every gear except first, was offered at no extra cost.
- It used a hydraulic clutch.
- Overdrive was locked out during rigorous acceleration above specified speeds and when a console switch was activated.
- Under the chassis were an aluminum drive shaft, forged-aluminum suspension arms, and a fiberglass transverse leaf spring.
- Power rack-and-pinion steering and power four-wheel disc brakes were standard.
- Optional Goodyear 50-series "uni-directional" tires were designed for mounting on a specific wheel.
- Inside, an electronic instrument panel featured both analog and digital LCD readouts in either English or metric measure.
- A Driver Information System between the speedometer and tachometer gave a selection of switch-chosen readings.
- At the driver's left was the parking brake.
- Corvette's ample standard equipment list included an advanced (and very necessary) theft-prevention system with starter-interrupt.
- Other standard equipment included: air conditioning; power windows; electronic-tuning seek/scan AM/FM stereo radio with digital clock; reclining bucket seats; leather-wrapped tilt/telescope steering wheel; luggage security shade; and side window defoggers.
- Body colors were
- White
- Bright Silver Metallic
- Medium Gray Metallic
- Black
- Light Blue Metallic
- Medium Blue Metallic
- Gold Metallic
- Light Bronze Metallic
- Dark Brown Metallic
- Bright Red
- Two-tone options were
- Silver and Medium Gray
- Light Blue and Medium Blue
- Light Bronze and Dark Bronze
- Interior colors came in Carmine; Bronze; Graphite; Medium Blue; Medium Gray; and Saddle
V.I.N. NUMBERS
- The serial number [Vehicle Identification Number -- VIN] was stamped on a plate on the inner vertical surface of the left windshield pillar visible through the windshield.
- The Serial numbers ranged from 1G1AY07*2E5100001 to 1G1AY07*2E5151547
Position |
Character |
Description |
1 |
1 |
US built |
2 |
G |
General Motors product |
3 |
1 |
Chevrolet Motor Division vehicle |
4 |
A |
Type of non-passive passenger restraint system |
5 |
Y |
Corvette car line series |
6 & 7 |
07 |
Body style number: two-door hatchback coupe |
8 |
8 |
5.7-liter Cross-Fire Injection (CFI) Chevrolet V8 |
9 |
? |
A check digit that calculates the characters in the serial number and gives it a single digit code and can be used to verify that the serial number is legitimate |
10 |
E |
The model year 1984 |
11 |
5 |
Bowling Green, KY |
12-17 |
100001 and up |
production sequence |
- Engine serial number began 0001001
- Corvette engines have the last six digits of the VIN stamped on the block just ahead of the cylinder head on the right-hand side combined with a three-letter engine code suffix
- Also cast into the top rear of the block is a four-symbol code indicating when the engine was built
- The first letter of the date code shows the month the block was cast
- The one or two numbers shows the month
- The last digit shows the year
- Engine suffixes:
Code |
Engine |
Horsepower |
Compression |
Transmission |
Fuel Supply |
Emission Control System |
ZFC |
L83 350-cid |
205-hp V-8 |
9.0:1 |
THM automatic |
cross-fire fuel injection |
|
ZFD |
L83 350-cid |
205-hp V-8 |
9.0:1 |
manual |
cross-fire fuel injection |
|
ZFF |
L83 350-cid |
205-hp V-8 |
9.0:1 |
THM automatic |
cross-fire fuel injection |
California |
ZFH |
L83 350-cid |
205-hp V-8 |
9.0:1 |
THM automatic |
cross-fire fuel injection |
for export |
ZFJ |
L83 350-cid |
205-hp V-8 |
9.0:1 |
manual |
cross-fire fuel injection |
for export |
ZFK |
L83 350-cid |
205-hp V-8 |
9.0:1 |
THM automatic |
cross-fire fuel injection |
|
ZFM |
L83 350-cid |
205-hp V-8 |
9.0:1 |
THM automatic |
cross-fire fuel injection |
California |
ZFN |
L83 350-cid |
205-hp V-8 |
9.0:1 |
THM automatic |
cross-fire fuel injection |
California |
ZFR |
L83 350-cid |
205-hp V-8 |
9.0:1 |
THM automatic |
cross-fire fuel injection |
California |
- The 1984 Corvette exterior colors were:
- 10 = White
- 16 = Bright Silver
- 18 = Medium Gray Metallic
- 19 = Black
- 20 = Light Blue Metallic
- 23 = Medium Blue Metallic
- 53 = Gold Metallic
- 63 = Light Bronze Metallic
- 66 = Dark Bronze Metallic
- 72 = Bright Red
- 16/18 = Silver and Medium Gray
- 20/23 = Light Blue and Medium Blue
- 83/66 = Light Bronze and Dark Bronze
- Upholstery Codes
Color |
Cloth & Leather Upholstery |
Sport Cloth Upholstery |
Leather Upholstery |
Green |
12C |
12V |
|
Medium Gray |
15C |
15V |
152 |
Medium Blue |
28C |
28V |
|
Saddle |
62C |
62V |
622 |
Bronze |
65C |
65V |
652 |
Graphite |
|
|
122 |
Carmine |
|
|
742 |
IDENTIFICATION
Model |
Model No. |
Body/Style No. |
Body Type |
Factory Price |
Shipping Weight |
Production Total |
Corvette |
1Y |
Y07 |
2-dr. Hatch Coupe - 2 passenger
|
$21,800 |
3088 |
51,547 |
ENGINE
Feature |
Standard Engine (RPO L83) |
Type |
V-8, 90-degree Overhead valve |
Block |
Cast iron block |
Displacement |
350 cid (5.7 liters) |
Bore & Stroke |
4.00" x 3.48" |
Compression ratio |
9.0:1 |
Brake horsepower |
205 @ 4200 |
Torque |
290 lb-ft @ 2800 |
Main bearing |
five |
Valve lifters |
hydraulic |
Fuel supply |
Cross-fire fuel injection (twin TBI - throttle body injection) |
TRANSMISSION
- Automatic Transmission
- Four-speed Turbo Hydra-Matic (TMH 700-R4)
- floor-mounted gear shifter
- gear ratios
- 1st = 3.06:1
- 2nd = 1.63:1
- 3rd = 1.00:1
- 4th = 0.70:1
- Rev = 2.29:1
- Final drive ratio: 2.73:1
- Manual Transmission
- Four-speed manual with overdrive
- floor-mounted gear shifter
- gear ratios
- 1st = 2.88:1
- 2nd = 1.91:1
- 3rd = 1.33:1
- 4th = 1.00:1
- overdrive = 0.67:1
- Rev = 2.78:1
- Final drive ratio: 3.07:1 (optional 3.31:1)
CHASSIS
Feature |
Coupe |
Wheelbase |
96.2 inches (2.443 m) |
Overall length |
176.5 inches (4.483 m) |
Overall width |
71.0 inches (1.803 m) |
Overall height |
46.7 inches (1.186 m) |
Front tread |
59.6 inches (1.514 m) |
Rear tread |
60.4 inches (1.534 m) |
Standard Wheel size |
15 x 7 inches |
Optional Wheel size |
16 x 8 inches |
Standard Tires |
P215/65R-15 |
Optional Tires |
P225/50VR-16 |
Steering |
rack and pinion (power assisted) |
Front suspension |
Single fiberglass composite monoleaf transverse spring with unequal-length aluminum control arms and stabilizer bar |
Rear suspension |
Fully independent five-link system with transverse fiberglass single-leaf springs, aluminum upper/lower trailing links and strut-rod tie-rod assembly |
Brakes |
Four-wheel power disc |
Body construction |
Unibody with partial front frame |
Fuel tank |
20 US Gal (16.7 Imp Gal) (76 liters) |
OPTIONS
RPO AG9 |
Power driver seat |
$210 |
RPO AQ9 |
Sports cloth seats |
$210 |
RPO AR9 |
Base leather seats |
$400 |
RPO AU3 |
Power door locks |
$165 |
RPO CC3 |
Removable transparent roof panel |
$595 |
RPO D84 |
Two-tone paint |
$428 |
RPO FG3 |
Delco-Bilstein shock absorbers |
$189 |
RPO G92 |
Performance axle ratio |
$22 |
RPO KC4 |
Engine oil cooler |
$158 |
RPO K34 |
Cruise control |
$185 |
RPO MM4 |
Four-speed manual transmission |
no-cost option |
RPO QZD |
P255/50VR-16 tires and 16-inch wheels |
$561.20 |
RPO ULS |
Radio delete |
$331 credit |
RPO UM6 |
AM-FM stereo radio with cassette |
$153 |
RPO UN8 |
AM-FM stereo with Citizens Band |
$153 |
RPO UU8 |
Delco-Bose stereo system |
$895 |
RPO VO1 |
Heavy-duty radiator |
$57 |
RPO YF5 |
California emissions certification |
$75 |
RPO Z51 |
Performance handling package |
$600.20 |
RPO Z6A |
Rear window and side mirror defoggers |
$160 |
