1975 CORVETTE

Major changes for 1975 involved the following:

improved bumpers which looked the same
a catalytic converter
a new High-Energy ignition
the speedometer included kilometers-per-hour. In the USA, mph was the dominant display with km/hr in smaller characters and the odometer registering miles. In Canada, the reverse was true.
This was the last year for the Corvette convertible
Ten exterior colors were available
- Bright Blue
- Bright Green
- Bright Yellow
- Classic White
- Dark Red
- Medium Saddle
- Mille Miglia Red
- Orange Flame
- Silver
- Steel Blue
All convertibles came with a choice of Black or White soft tops
Interior colors were
- Black
- Dark Blue
- Dark Red
- Neutral
- Medium Saddle
- Silver

V.I.N. NUMBERS

The serial number [Vehicle Identification Number -- VIN] was stamped on a plate on the inner vertical surface of the left windshield pillar visible through the windshield.
Convertible Serial numbers ranged from 1Z67*5S400001 to 1Z67*5S438465
Coupe Serial numbers ranged from 1Z67*5S400001 to 1Z67*5S438465

Position	Character	Description
1	1	Chevrolet Division
2	Z	Corvette
3 & 4	67	convertible
3 & 4	37	coupe
5	*	Engine type where * is replaced by the following J = ZQ3 350-cid V8, 165-hp, 4-barrel T = L82 350-cid V8, 205-hp, 4-barrel
6	5	1975
7	S	Assembled in St. Louis, MO
8 to 13	400001 to 438465	production sequence

1 to 7	0001001	sequential production number
8	F or T	Flint, MI or Tonawanda, NY
9 to 11	Carburetion & transmission	Code	Engine	Compression	transmission	Carburetor
		CUB	350-cid 165-hp V-8	8.5:1	manual	four-barrel
		CUD	350-cid 205-hp V-8	9.0:1	manual	four-barrel
		CRK	350-cid V-8		THM-400 automatic	four-barrel
		CRL	350-cid V-8		manual	four-barrel
		CRM	350-cid V-8		THM-400 automatic	four-barrel
		CUT	350-cid V-8		manual	four-barrel
		CUA	350-cid V-8		manual	four-barrel

Corvette engines have the last six digits of the VIN stamped on the block next to the engine number
The body number plate was located on the engine side of the cowl.
The Fisher Body Style Number 75-1YZ67 identifies a Corvette Stingray convertible
The Fisher Body Style Number 75-1YZ37 identifies a Corvette Stingray coupe
The body number is the production serial number of the body.
The trim number indicates the interior trim color and material.
The ten 1975 Corvette exterior colors were:
- 22 = Bright Blue
- 42 = Bright Green
- 56 = Bright Yellow
- 10 = Classic White
- 74 = Dark Red
- 67 = Medium Saddle
- 76 = Mille Miglia Red
- 70 = Orange Flame
- 13 = Silver
- 27 = Steel Blue
Upholstery Codes

Series No.	Body/Style No.	Body Type	Factory Price	Shipping Weight	Production Total
Z	37	2-dr. Sport Coupe with T-tops - 2 passenger	$6810	3532	33,836
Z	67	2-dr. Conv - 2 passenger	$6550	3532	4,629

Feature	Standard Engine (RPO ZQ3)	Optional Engine (RPO L82)
Type	V-8, Overhead valve
Block	Cast iron block
Displacement	350 cid	350 cid
Bore & Stroke	4.00 x 3.48"	4.00 x 3.48"
Compression ratio	8.5:1	9.0:1
Brake horsepower	165 @ 3800	205 @ 4800
Torque	255 lb-ft @ 2400	255 lb-ft @ 3600
Main bearing	five
Valve lifters	hydraulic
Camshaft		High-performance camshaft
Fuel supply	Rochester Quadra-Jet four-barrel Model 4MV	Rochester Quadra-Jet four-barrel

Standard Manual Transmission
close-ratio four-speed manual all-synchromesh transmission with floor-mounted gear shifter
Automatic Transmission
Three-speed Turbo Hydra-Matic automatic transmission with floor-mounted gear shifter (optional)

Feature	Convertible	Coupe
Wheelbase	98 inches (2.489 m)	98 inches (2.489 m)
Overall length	185.5 inches (4.712 m)	185.5 inches (4.712 m)
Overall width	69.0 inches (1.753 m)	69.0 inches (1.753 m)
Overall height		47.4 inches (1.204 m)
Ground Clearance	4.5 inches (11.4 cm)	4.5 inches (11.4 cm)
Front tread	58.7 inches (1.491 m)	58.7 inches (1.491 m)
Rear tread	59.4 inches (1.509 m)	59.4 inches (1.509 m)
Tires	F70-15	F70-15
Frame	Full-length welded-steel ladder type with five cross members. Steel box sections, welded.
Front suspension	Independent, unequal-length A-arms, coil springs; tubular shocks and stabilizer bar
Rear suspension	Independent, trailing arms, toe links, transverse chromium-carbon steel leaf spring, tube shocks, and anti-roll bar
Steering	Saginaw recirculating ball, 17.6:1 ratio, 2.9 turns to lock, 39.0 turning circle
Rear axle type	Sprung differential, Hypoid gear
Brakes	Hydraulic, vented four wheel discs; 11.75-inch diameter, single calipers, optional power assist
Swept area	11.75" front and back
Total swept area	461 sq. in.
Wheels	8" wide slotted steel 15" 5-lug disc
Standard rear axle ratio	3.36:1
Optional rear axle ratio	3.70:1, 3.08:1, 3.36:1, 3.55:1

RPO	Custom interior trim	$154
RPO A31	Electric power windows	$93
RPO A85	Custom shoulder belts	$41
RPO C07	Auxiliary hardtop for convertible	$267
RPO C08	Vinyl cover for auxiliary hardtop	$350
RPO C50	Rear window defroster	$46
RPO C60	Air conditioning	$490
RPO FE7G81	Gymkhana suspension	$7
RPO G81	Positraction rear axle, all ratios	$12
RPO J50	Power brakes	$50
RPO L82	350-cid 205-hp V-8	$336
RPO M21	Four-speed close-ratio manual transmission	n/c
RPO M40	Turbo Hydra-Matic automatic transmission	n/c
RPO N37	Tilt-telescopic steering wheel	$82
RPO N40	Power steering	$129
RPO QRM	White stripe nylon steel-belted radial tires GR70 x 15	$35
RPO QRZ	GR70 x 15 raised-white-letter steel-belted radial tires	$48
RPO U05	Dual horns	$4
RPO U58	AM-FM radio	$284
RPO U69	AM-FM radio	$178
RPO UA1	Heavy-duty battery	$15
RPO UF1	Map light	$5
RPO Z07	Off-road suspension and brake package	$400

1975 Corvette Notes

The 454-cid engine was dropped this year in all Corvettes
The convertible was also dropped
Car and Driver tested a 1975 and found that it did the quarter-mile in 16.1 seconds and did 0-to-60 in 7.7 seconds with a top speed of 129 mph
Robert D. Lund became Chevrolet general manager
Zora Arkus-Duntov retired as Chevrolet's chief engineer.
David R. McLellan became the chief engineer.

1975 Corvette
