Pontiac introduced its new 17-symbol Vehicle Identification Number (VIN) | ||
---|---|---|
It was located on the upper left surface of the instrument panel, visible through the windshield | ||
Position | Character | Description |
1 | 1 | US built |
2 | G | General Motors product |
3 | 2 | Pontiac Motor Division vehicle |
4 | A | Manual seatbelts |
5 | S | Firebird |
T | Esprit | |
V | Formula | |
W | Trans Am | |
X | Trans Am Turbo Special Edition | |
6 & 7 | 87 | Body style number: two-door plainback special coupe |
8 | * | Engine type where * is replaced by the following
|
9 | ? | A check digit that calculates the characters in the serial number and gives it a single digit code and can be used to verify that the serial number is legitimate |
10 | B | The model year where B = 1981 |
11 | _ | Manufacturing plant code |
12-17 | 100001 and up | Production sequence serial number |
Model Number | Style Number | Body Type | Seating | Factory Price | Shipping Weight | Production Total |
---|---|---|---|---|---|---|
2F | S87 | 2-door Hardtop Base Firebird - V6 | 4 | $6901 | 3275 | 20,541 both 6 & V8 |
2F | S87 | 2-door Hardtop Base Firebird - V8 | 4 | $6951 | 3350 | |
2F | T87 | 2-door Hardtop Esprit - V6 | 4 | $7646 | 3312 | 10,938 |
2F | T87 | 2-door Hardtop Esprit - V8 | 4 | $7695 | 3472 | |
2F | V87 | 2-door Hardtop Formula - V6 | 4 | $7854 | 3397 | 5,927 |
2F | V87 | 2-door Hardtop Formula - V8 | 4 | $7904 | 3472 | |
2F | W87 | 2-door Hardtop Trans Am | 4 | $8322 | 3419 | 33,493 |
2F | X87 | 2-door Hardtop Trans Am Turbo SE | 4 | $12,257 |
VIN Code | A (Buick) | S | W | E/C | T (turbocharged) | H (Calif.) |
---|---|---|---|---|---|---|
Cylinders | 90° V-6 | 90° V-8 | 90° V-8 | 90° V-8 | 90° V-8 | 90° V-8 |
Valving | Overhead valve | Overhead valve | Overhead valve | Overhead valve | Overhead valve | Overhead valve |
Block | Cast-iron | Cast-iron | Cast-iron | Cast-iron | Cast-iron | Cast-iron |
Head | Cast-iron | Cast-iron | Cast-iron | Cast-iron | Cast-iron | Cast-iron |
Bore & Stroke | 3.80 x 3.40 in. | 3.75 x 3.00 in. | 4.00 x 3.00 in. | 4.00 x 3.00 in. | 4.00 x 3.00 in. | 3.74 x 3.48 |
Displacement | 231 cid (3.8 liters) | 265 cid (4.3 liters) | 301 cid (5.0 liters) | 301 cid (5.0 liters) | 301 cid (5.0 liters) | 305 cid (5.0 liters) |
Compression ratio | 8.0 : 1 | 8.3 : 1 | 8.1 : 1 | 8.4 : 1 | 7.5 : 1 | 8.4 : 1 |
Brake H.P. | 110 @ 3800 rpm | 120 @ 4000 | 135 @ 3600 rpm | 150 @ 4000 rpm | 200 @ 4000 rpm | 145 @ 3800 rpm |
Torque (lb-ft) | 190 @ 1600 rpm | 205 @ 2000 rpm | 235 @ 1600 rpm | 245 @ 2000 rpm | 340 @ 2000 rpm | 240 @ 2400 rpm |
Main bearings | Four | Five | Five | Five | Five | Five |
Valve lifters | Hydraulic | |||||
Carburetor | 2-barrel Rochester M2ME | 2-barrel Rochester E2ME | 4-barrel Rochester E4ME | 4-barrel Rochester E4ME | 4-barrel Rochester E4ME | 4-barrel Rochester E4ME |
Three-speed manual floor shift |
Four-speed manual shift |
Three-speed automatic |
FEATURE | Firebird | Esprit | Formula | Trans Am |
---|---|---|---|---|
Wheelbase | 108.2 in. | 108.2 in. | 108.2 in. | 108.2 in. |
Overall length | 196.1 in. | 196.1 in. | 196.1 in. | 196.1 in. |
Height | 49.3 in. | 49.3 | 49.5 | 49.5 |
Width | 73.0 | 73.0 | 73.0 | 73.0 |
Front tread | 60.9 | 60.9 | 61.3 | 61.2 |
Rear tread | 60.0 | 60.0 | 60.4 | 60.3 |
Tires | P205/75R15 | P205/75R15 | P225/70R15 SBR | P225/70R15 SBR |
Steering | Recirculating ball | |||
Front suspension | coil springs with lower trailing links and anti-sway bar | |||
Rear suspension | semi-elliptic leaf springs with anti-sway bar | |||
Brakes | Front disc, rear drums | Front disc, rear disc | ||
Ignition | Electronic | |||
Body construction | Unit with separate partial frame | |||
Fuel tank | 21 gal |
1981 Firebird Notes
