Pontiac introduced its new 17-symbol Vehicle Identification Number (VIN) | ||
---|---|---|
It was located on the upper left surface of the instrument panel, visible through the windshield | ||
Position | Character | Description |
1st | 1 | US built |
2nd | G | General Motors product |
3rd | 2 | Pontiac Motor Division vehicle |
4th | A | Manual seatbelts |
5th | S | Firebird |
X | SE | |
W | Trans Am | |
6th & 7th | 87 | Body style number: two-door plainback special coupe |
8th | * | Engine type where * is replaced by the following
|
9th | ? | A check digit that calculates the characters in the serial number and gives it a single digit code and can be used to verify that the serial number is legitimate |
10th | C | The model year where C = 1982 |
11th | _ | Manufacturing plant code |
12th to 17th | 100001 and up | Production sequence serial number |
Model Number | Style Number | Body Type | Seating | Factory Price | Shipping Weight | Production Total |
---|---|---|---|---|---|---|
2F | S87 | 2-door Hardtop Base Firebird - Four | 4 | $7996 | 41,863 both 4 & V8 | |
2F | S87 | 2-door Hardtop Base Firebird - V6 | 4 | $8121 | ||
2F | X87 | 2-door Hardtop SE - V6 | 4 | $9624 | 21,719 | |
2F | X87 | 2-door Hardtop SE - V8 | 4 | $9819 | ||
2F | W87 | 2-door Hardtop Trans Am - V8 | 4 | $9658 | 52,960 |
VIN Code | R or 2 | X or 1 | H (Chev) | 7 |
---|---|---|---|---|
Cylinders | Four (inline) | 60° V-6 | 90° V-8 | 90° V-8 |
Valving | Overhead valve | Overhead valve | Overhead valve | Overhead valve |
Block | Cast-iron | Cast-iron | Cast-iron | Cast-iron |
Head | Cast-iron | Aluminum | Cast-iron | Cast-iron |
Bore & Stroke | 4.00 x 3.00 in. | 3.50 x 3.00 in. | 3.74 x 3.48 in. | 4.00 x 3.00 in. |
Displacement | 151 cid (2.5 liters) | 173 cid (2.8 liters) | 305 cid (5.0 liters) | 305 cid (5.0 liters) |
Compression ratio | 8.2 : 1 | 8.5 : 1 | 8.6 : 1 | 9.5 : 1 |
Brake H.P. | 90 @ 4000 rpm | 105 @ 4800 | 145 @ 4000 rpm | 165 @ 4200 rpm |
Torque (lb-ft) | 134 @ 2400 rpm | 142 @ 2400 rpm | 240 @ 2000 rpm | 240 @ 2400 rpm |
Main bearings | Five | Four | Five | Five |
Valve lifters | Hydraulic | |||
Carburetor | Throttle-body fuel injection | 2-barrel Rochester E2SE | 4-barrel Rochester E4ME | Throttle-body fuel Injection |
Four-speed Transmission | Standard |
Three-speed Turbo-Hydra-Matic | Optional |
Final drive ratio with V-6 | 3.23 : 1 |
Final drive ratio with V-8 | 3.23 : 1 |
FEATURE | Firebird | SE | Trans Am |
---|---|---|---|
Wheelbase | 101.0 in. | 101.0 in. | 101.0 in. |
Overall length | 189.8 in. | 189.8 in. | 189.8 in. |
Height | 49.8 in. | 49.8 | 49.8 |
Width | 72.0 | 72.0 | 72.0 |
Front tread | 60.7 | 60.7 | 60.7 |
Rear tread | 60.6 | 60.6 | 60.6 |
Tires | P195/75R14 GBR BSW | P205/70R14 SBR BSW | P205/70R14 SBR BSW |
Steering | Recirculating ball | ||
Front suspension | Modified MacPherson struts with coil springs between lower control arm and X-member | ||
Rear suspension | Torque arm/track bar with coil springs | Torque arm/track bar with coil springs and anti-sway bar | |
Brakes | Front disc, rear drums | ||
Ignition | Electronic | ||
Body construction | Unit | ||
Fuel tank | 16 gal |
1982 Firebird Notes
