Four models of the Firebird were available:
|
|
|
|
|
|
|
|
VIN Location | On top of dash at left, viewable through windshield | |
---|---|---|
Position | Character | Description |
1 | 2 | General Motors: Pontiac Division |
2 | S | Basic Firebird |
T | Firebird Esprit | |
U | Firebird Formula | |
V | Trans Am | |
3 & 4 | 87 | hardtop coupe |
5 | _ | Engine code (see listing in engine section) |
6 | 4 | Year: 1974 |
7 | _ | Assembly plant |
8 to 13 | 100001 and up | production sequence |
Model Number | Style Number | Body Type | Seating | Factory Price | Shipping Weight | Production Total |
---|---|---|---|---|---|---|
2FS | S87 | 2-door Hardtop Base Firebird - 6 cyl | 4 | $3335 | 3283 | 26,372 both 6 & V8 |
2FS | S87 | 2-door Hardtop Base Firebird - V8 | 4 | $3460 | 3504 | |
2FT | T87 | 2-door Hardtop Esprit | 4 | $3687 | 3540 | 22,583 |
2FU | U87 | 2-door Hardtop Formula | 4 | $3659 | 3548 | 14,510 |
2FV | V87 | 2-door Hardtop Trans Am | 4 | $4446 | 3655 | 10,255 |
MODEL | Code | Type | Displacement | Carb | Compression | Net HP |
---|---|---|---|---|---|---|
Base Firebird (std) | D | 6-cyl | 250 cid | 1-V | 8.2:1 | 100 @ 3600 rpm |
Base Firebird (opt) | M | V-8 | 350 cid | 2-V | 7.6:1 | 155 @ 4000 rpm |
Esprit (std) | M | V-8 | 350 cid | 2-V | 7.6:1 | 155 @ 4000 rpm |
Esprit (opt) | R | V-8 | 400 cid | 2-V | 7.6:1 | 175 @ 3600 rpm |
Formula (std) | M | V-8 | 350 cid | 2-V | 7.6:1 | 155 @ 4000 rpm |
Formula (opt) | R | V-8 | 400 cid | 2-V | 7.6:1 | 175 @ 3600 rpm |
Formula (opt) | T | V-8 | 400 cid | 4-V | 8.0:1 | 255 @ 4000 rpm |
Formula (opt) | Y | V-8 | 455 cid | 4-V | 8.0:1 | 250 @ 4000 rpm |
Formula (opt) | X (LS2) | V-8 | 455 cid | 4-V | 8.4:1 | 290 @ 4000 rpm |
Trans Am (std) | T | V-8 | 400 cid | 4-V | 8.0:1 | 255 @ 4000 rpm |
Trans Am (opt) | Y | V-8 | 455 cid | 4-V | 8.0:1 | 250 @ 4000 rpm |
Trans Am (opt) | X (LS2) | V-8 | 455 cid | 4-V | 8.4:1 | 290 @ 4000 rpm |
3-speed manual |
4-speed manual |
M38 Turbo-Hydra-Matic |
M40 Turbo-Hydra-Matic |
Wheelbase | Overall length | Front tread | Rear tread |
---|---|---|---|
108 in. | 196 in. | 60 in. | 60 in. |
1974 Firebird Notes
