2001 VT1100C'01 SHADOW SPIRIT 1100
ENGINE
Engine Type: Liquid cooled, 45° V-twin, dual offset pin crank
Displacement: 1099cc
Bore and Stoke: 87.5mm x 91.4mm
Compression Ratio: 8:1
Valve Train: SOHC, 3 valve per cylinder, self-adjusting hydraulic
Fuel Delivery: Twin 36mm, diaphragm-type CV
DRIVETRAIN
Transmission: Wide-Ratio, 5-speed
Final Drive: Shaft
CHASSIS / SUSPENSION / BRAKES
Front Suspension: 41mm fork, 160mm travel
Rear Suspension: Dual shocks with 5-way spring preload adjustment, 100mm travel
Front Tire: 110/90H-19
Rear Tire: 170/80H-16
Front Brakes: Single 336mm disc with twin piston caliper
Rear Brakes: Mechanical drum
DIMENSION
Seat Height: 730mm (28.7")
Wheelbase: 1651mm (65.0")
Dry Weight: 251 kg (553 lb)
Fuel Capacity: 15.8 liters
OTHER
2001 VT1100C
2003 VT1100C'03
ENGINE
Engine: 1099cc liquid-cooled, 45-degree V-twin, dual off-set crankpin
Bore and Stroke: 87.5mm x 91.4mm
Compression Ratio: 8.0: 1
Valve Train: SOHC; three valves per cylinder, self adjusting hydraulic
Fuel Delivery: Two 36mm diaphragm-type CV
DRIVETRAIN
Transmission: Five-speed wide ratio
Final Drive: Shaft
CHASSIS / SUSPENSION / BRAKES
Front Suspension: 41mm fork; 160mm travel
Rear Suspension: Dual shocks with five-position spring preload adjustability; 100mm travel
Front Brakes: Single 336mm disc with twin-piston caliper
Rear Brake: Drum
Front Tire: 110/90-19
Rear Tire: 170/80-15
DIMENSION
Wheelbase: 1650mm (65.0 in.)
Seat Height: 730mm (28.7 in.)
Dry Weight: 251kg (553 lbs.)
Fuel Capacity: 15.8 Litres (4.2 GalUS)
OTHER
2003 VT1100C
2004 Shadow Spirit 1100
2004 VT1100C
2004 VT1100C
Engine Type: 1099cc liquid-cooled 45-degree V-twin
Bore and Stroke: 87.5mm x 91.4mm
Compression Ratio: 8.0:1
Valve Train: SOHC; three valves per cylinder
Fuel Delivery: Two 36mm CV
Ignition: Solid-state digital, two spark plugs per cylinder
Transmission: Five-speed
Final Drive: Shaft
Front Suspension: 41mm fork; 6.3-inch travel
Rear Suspension: Dual shocks with five-position spring-preload adjustability; 3.9-inch travel
Front Brake: Single disc with twin-piston caliper
Rear Brake: Drum
Front Tire: 110/90-19
Rear Tire: 170/80-15
Wheelbase: 65.0 inches
Seat Height: 28.7 inches
Dry Weight: 553.0 pounds
Fuel Capacity: 4.2 gallons, including 0.6-gallon reserve
Emissions: California version differs slightly due to emissions equipment.
Colors:
Model ID: VT1100C
Warranty: 1 year
2005 Shadow Spirit 1100
2005 VT1100C
2005 VT1100C
Engine Type: 1099cc liquid-cooled 45-degree V-twin
Bore and Stroke: 87.5mm x 91.4mm
Compression Ratio: 8.0:1
Valve Train: SOHC; three valves per cylinder
Fuel Delivery: Two 36mm CV
Ignition: Digital, two spark plugs per cylinder
Transmission: Five-speed
Final Drive: Shaft
Front Suspension: 41mm fork; 6.3-inch travel
Rear Suspension: Dual shocks with five-position spring-preload adjustability; 3.9-inch travel
Front Brake: Single disc with twin-piston caliper
Rear Brake: Drum
Front Tire: 110/90-19
Rear Tire: 170/80-15
Wheelbase: 65.0 inches
Seat Height: 28.7 inches
Dry Weight: 553.0 pounds
Fuel Capacity: 4.2 gallons, including 0.6-gallon reserve
Emissions: California version differs slightly due to emissions equipment.
Colors:
Model ID: VT1100C
Warranty: 1 year
2006 VT1100C Shadow Spirit
2006 vt1100c Shadow Spirit
2006 vt1100c Shadow Spirit
Engine Type: 1099cc liquid-cooled 45-degree V-twin
Bore and Stroke: 87.5mm x 91.4mm
Compression Ratio: 8.0:1
Valve Train: SOHC; three valves per cylinder
Fuel Delivery: Two 36mm CV
Ignition: Digital, two spark plugs per cylinder
Transmission: Five-speed
Final Drive: Shaft
Front Suspension: 41mm fork; 6.3-inch travel
Rear Suspension: Dual shocks with five-position spring-preload adjustability; 3.9-inch travel
Front Brake: Single disc with twin-piston caliper
Rear Brake: Drum
Front Tire: 110/90-19
Rear Tire: 170/80-15
Rake: 32-degrees 40'
Trail: 152.5mm (6.0 inches)
Wheelbase: 65.0 inches
Seat Height: 28.7 inches
Dry Weight: 556.0 pounds
Fuel Capacity: 4.2 gallons, including 0.6-gallon reserve
Emissions: California version differs slightly due to emissions equipment.
Colors:
Black
Bright Blue Metallic
Model ID: VT1100C
2007 VT1100C Shadow Spirit
2007 VT100C Shadow Spirit
2007 VT100C Shadow Spirit
Overview: Taking its styling cues straight from classic cruisers of old, the Shadow Spirit boasts a seamless blend of retro panache and modern-day performance. With its bobbed rear fender, pullback handlebar and low seat complementing classic 2-into-2 "shorty" pipes and a beefy 1099cc V-twin, the Spirit is a beauty unlike few others.
Engine Type: 1099cc liquid-cooled 45-degree V-twin
Bore and Stroke: 87.5mm x 91.4mm
Compression Ratio: 8.0:1
Valve Train: SOHC; three valves per cylinder
Fuel Delivery: Two 36mm CV
Ignition: Digital, two spark plugs per cylinder
Transmission: Five-speed
Final Drive: Shaft
Front Suspension: 41mm fork; 6.3-inch travel
Rear Suspension: Dual shocks with five-position spring-preload adjustability; 3.9-inch travel
Front Brake: Single disc with twin-piston caliper
Rear Brake: Drum
Front Tire: 110/90-19
Rear Tire: 170/80-15
Rake: 32-degrees 40'
Trail: 152.5mm (6.0 inches)
Wheelbase: 65.0 inches
Seat Height: 28.7 inches
Dry Weight: 556.0 pounds
Fuel Capacity: 4.2 gallons, including 0.6-gallon reserve
Emissions: California version differs slightly due to emissions equipment.
Colors:
Model ID: VT1100C
2008 VT1100C Shadow Spirit
ENGINE
Engine Size: 1099cc
Engine Detail: liquid-cooled 45 degree V-twin
Bore Stroke: 87.5mm x 91.4mm
Compression Ratio: 8.0:1
Fuel System: Two 36mm CV
Ignition: Digital, two spark plugs per cylinder
DRIVETRAIN
Transmission: Five-Speed
Final Drive: Shaft
CHASSIS / SUSPENSION / BRAKES
Suspension Front: 41mm fork; 6.3-inch travel
Suspension Rear: Dual shocks with five-position spring-preload adjustability; 3.9-inch travel
Brakes Front: Single disc with twin-piston caliper
Brakes Rear: Drum
Tire Front: 110/90-19
Tire Rear: 170/80-15
DIMENSION
Wheelbase: 65.0 in.
Seat Height: 28.7 in.
Curb Weight: N/A lbs.
Fuel Capacity: 4.2 gal.
OTHER
Colors: Black, Metallic Silver
Price: $8699
Warranty: 1 Year
2008 VT100C Shadow Spirit
2008 VT100C Shadow Spirit
