2012 CBF1000F
- ENGINE
- Engine Type: Inline 4 Cylinder, Liquid-cooled 4-stroke, 16-valve DOHC
- Engine Displacement: 998 cc
- Bore and Stroke: 75 x 56.5 mm
- Compression Ratio: 11:1
- Fuel Delivery: PGM-FI electronic fuel injection
- Ignition: Computer-controlled digital transistorised with electronic advance
- Max. Power Output: 79kW/9,000min-1 (95/1/EC)
- Max. Torque: 96Nm/6,500min-1 (95/1/EC)
- Starter: Electric
- DRIVETRAIN
- Transmission: 6-speed
- Final Drive: #530 O-ring sealed chain
- Front Wheels: 17M/C x MT3.50 hollow-section 6-spoke cast aluminium
- Rear Wheels: 17M/C x MT5.00 hollow-section 6-spoke cast aluminium
- CHASSIS / SUSPENSION / BRAKES
- Front Suspension: 41 mm cartridge-type telescopic fork, 120 mm axle travel
- Rear Suspension: Pro-Link with gas-charges HMAS damper, 120 mm axle travel
- Front Brakes: 296 x 4.5 mm dual hydraulic disc with 3-piston calipers, ABS floating rotors and sintered metal pads
- Rear Brakes: 240 x 6 mm hydraulic disc with 3-piston caliper, ABS and sintered pads
- Front Tires: 120/70 ZR17M/C (58W)
- Rear Tires: 160/60 ZR17M/C (69W)
- DIMENSION
- Wheelbase: 1483 mm (58.4 inches)
- Overall Length: 2210mm (87 inches)
- Overall Width: 780mm (30.7 inches)
- Overall Height: 1220mm (48 inches)
- Seat Height: 795 mm (31.3 inches) [±15 mm (0.6 inch)]
- Ground Clearance: 135 mm (5.3 inches)
- Weight: 245 kg (539 lb)
Front: 120 kg (264 lb)
Rear: 125 kg (275 lb)
- Fuel Capacity: 20 Litres (5.3 GalUS)
- OTHER
