Honda Super Hawk CB77 Motorcycles

1961-68 Honda Super Hawk 305 (CB77)

ENGINE
- Engine: Air cooled, four stroke, parallel twin cylinder SOHC
- Displacement: 305cc
- Bore and Stroke: 60 x 54 mm
- Compression Ratio: 9.5:1
- Carburetors: Twin
- Starter: Kickstart
- Max Power: 16.8 KW (23.8 hp) @ 7500 rpm
- Max Torque: 23.1 NM @ 6000 rpm
DRIVETRAIN
- Transmission: 4-speed
- Clutch: Wet multi-plate
- Final Drive: Chain
CHASSIS / SUSPENSION / BRAKES
- Front Suspension: Hydra lick forks
- Rear Suspension: Dual chocks
- Front Brakes: Drum
- Rear Brakes: Drum
- Front Tire: 3.25-16
- Rear Tire: 3.25-16
DIMENSION
- Seat Height: 785 mm (30.9 in.)
- Dry-Weight: 169 kg (372 lb)
- Fuel Capacity: N/A
OTHER
- Colors:
  - Blue
  - Scarlet Red
  - Black
  - White
- The fuel tank, forks, headlight shell, and frame were painted one of the basic colors
- The fenders and side covers were silver
- The lower front forks on early models were painted one of the basic colors, but later they were silver
- The tank panel was chrome with rubber knee pads
- The early models had a flat handlebar, but the later models had a low rise handlebar
- The serial number began CB77-100001.
