Honda XR125 Motorcycles

2004 XR125L

ENGINE
- Engine Type: Air-cooled 4-stroke OHV single
- Engine Displacement: 124cc
- Bore & Stroke: 56.5 x 49.5mm
- Compression Ratio: 9.5 :1
- Fuel Delivery: 22mm PD-type carburetor
- Max. Power Output: 8.3kW/8500min-1 (95/1/EC)
- Max. Torque: 10Nm/7000min-1 (95/1/EC)
- Ignition: Digital transistorised with electronic advance
- Starter: Electric
DRIVETRAIN
- Transmission: 5-speed
- Final Drive: Roller chain
- Front Wheel: 19 x MT1.85
- Rear Wheel: 17 x MT2.15
CHASSIS / SUSPENSION / BRAKES
- Front Suspension: 31mm telescopic fork, 180mm axle travel
- Rear Suspension: Monoshock damper, 160mm axle travel
- Front Brakes: 240mm hydraulic disc with dual-piston caliper and resin mould pads
- Rear Brakes: 110mm leading/trailing drum
- Front Tire: 90/90-19 64J
- Rear Tire: 110/90-17 64J
DIMENSION
- Length x Width x Height: (LxWxH) 2060 x 810 x 1130mm
- Wheelbase: 1350mm
- Seat Height: 820mm
- Ground Clearance: 250mm
- Fuel Capacity: 12 litres (including 4.1-litre reserve)
- Dry Weight: 115.5kg
OTHER

ENGINE
- Engine Type: Air-cooled 4-stroke OHV single
- Engine Displacement: 124cm3
- Bore & Stroke: 56.5 x 49.5mm
- Compression Ratio: 9.5 :1
- Carburation: 22mm PD-type carburetor
- Max. Power Output: 8.3kW/8,500min-1 (95/1/EC)
- Max. Torque: 10Nm/7,000min-1 (95/1/EC)
- Ignition: Digital transistorised with electronic advance
- Starter: Electric
DRIVETRAIN
- Transmission: 5-speed
- Final Drive: Roller chain
- Wheels Front: 19 x MT1.85
- Wheels Rear: 17 x MT2.15
CHASSIS / SUSPENSION / BRAKES
- Suspension Front: 31mm telescopic fork, 180mm axle travel
- Suspension Rear: Monoshock damper, 160mm axle travel
- Brakes Front: 240mm hydraulic disc with dual-piston caliper and resin mould pads
- Brakes Rear: 110mm leading/trailing drum
- Tires Front: 90/90-19 64J
- Tires Rear: 110/90-17 64J
DIMENSION
- Length x Width x Height: 2,060 x 810 x 1,130mm
- Wheelbase: 1,350mm
- Seat Height: 820mm
- Ground Clearance: 250mm
- Fuel Capacity: 12 litres (including 4.1-litre reserve)
- Dry Weight: 115.5kg
OTHER
