Honda Varadero XL125V Motorcycles

2004 Varadero XL125V

ENGINE
- Engine Type: Liquid cooled 4-stroke 4-valve SOHC 90° V-twin
- Engine Displacement: 125cc
- Bore & Stroke: 42 x 45mm
- Compression Ratio: 11.8 :1
- Fuel Delivery: 22mm VP-type x 2
- Ignition: Dual digital transistorised with electronic advance
- Max. Power Output: 15 bhp at 11,080 rpm
- Max. Torque: 10.7Nm at 9,500 rpm
- Starter: Electric
DRIVETRAIN
- Transmission: 5-speed
- Final Drive: 'O'-Ring sealed chain
- Front Wheel: Hollow-section triple-spoke cast aluminum
- Rear Wheel: Hollow-section triple-spoke cast aluminum
CHASSIS / SUSPENSION / BRAKES
- Front Suspension: 35mm telescopic fork, 132mm axle travel
- Rear Suspension: Monoshock swingarm with adjustable spring preload, 150mm axle travel
- Front Brakes: 276mm hydraulic disc with dual-piston caliper
- Rear Brakes: 220mm hydraulic disc with single-piston caliper
- Front Tire: 100/90-18 (56P)
- Rear Tire: 130/80-17 (65P)
DIMENSION
- Overall Length: 2150mm (84.6 inches)
- Overall Width: 850mm (33.5 inches)
- Overall Height: 1250mm (49.2 inches)
- Wheelbase: 1450mm (57 inches)
- Seat Height: 802mm (31.5 inches)
- Ground Clearance: 190mm (7.5 inches)
- Fuel Capacity: 17.5 litres (4.6 Gal)(including 2 litre (0.5 Gal)reserve)
- Dry Weight: 149kg (328 lb)
OTHER

ENGINE
- Engine Type: Liquid cooled 4-stroke 4-valve SOHC 90° V-twin
- Engine Displacement: 125cc
- Bore & Stroke: 42 x 45mm
- Compression Ratio: 11.8:1
- Carburation: 22mm VP-type x 2
- Max. Power Output: 15 bhp at 11,080 rpm
- Max. Torque: 10.7Nm at 9,500 rpm
- Ignition: Dual digital transistorised with electronic advance
- Starter: Electric
DRIVETRAIN
- Transmission: 5-speed
- Final Drive: 'O'-Ring sealed chain
- Wheels Front: Hollow-section triple-spoke cast aluminium
- Wheels Rear: Hollow-section triple-spoke cast aluminium
CHASSIS / SUSPENSION / BRAKES
- Suspension Front: 35mm telescopic fork, 132mm axle travel
- Suspension Rear: Monoshock swingarm with adjustable spring preload, 150mm axle travel
- Brakes Front: 276mm hydraulic disc with dual-piston caliper
- Brakes Rear: 220mm hydraulic disc with single-piston caliper
- Tires Front: 100/90-18 (56P)
- Tires Rear: 130/80-17 (65P)
DIMENSION
- Overall Length: 2150mm (84.6 inches)
- Overall Width: 850mm (33.5 inches)
- Overall Height: 1250mm (49.2 inches)
- Wheelbase: 1450mm (57 inches)
- Seat Height: 802mm (31.5 inches)
- Ground Clearance: 190mm (7.5 inches)
- Fuel Capacity: 17.5 litres (4.6 Gal) [including 2 litre (.5 Gal) reserve]
- Dry Weight: 149kg (328 lb)
OTHER

ENGINE
- Engine Type: Liquid-cooled 4-stroke 4-valve SOHC 90° V-twin
- Engine Displacement: 125cc
- Bore and Stroke: 42 x 45mm
- Compression Ratio: 11.8:1
- Fuel Delivery: PGM-FI electronic fuel injection
- Ignition: Fully transistorised with electronic advance
- Max. Torque: 10Nm/8,500min-1 (95/1/EC)
- Max. Power Output: 10.6kW/11,000min-1 (95/1/EC)
- Starter: Electric
DRIVETRAIN
- Transmission: 5-speed
- Final Drive: O-ring sealed chain
- Front Wheels: Hollow-section triple-spoke cast aluminium, 18M/C x MT2.15
- Rear Wheels: Hollow-section triple-spoke cast aluminium, 17M/C x MT2.75
CHASSIS / SUSPENSION / BRAKES
- Front Suspension: 35mm telescopic fork, 132mm axle travel
- Rear Suspension: Monoshock swingarm with adjustable spring preload, 150mm axle travel
- Front Brakes: 276 x 4mm hydraulic disc with dual-piston caliper
- Rear Brakes: 220 x 4mm hydraulic disc with single-piston caliper
- Rear Tires: 130/80-17M/C (65P)
- Front Tires: 100/90-18M/C (56P)
DIMENSION
- Wheelbase: 1450mm (57 inches)
- Overall Length: 2150mm (84.6 inches)
- Overall Width: 833mm (32.8 inches)
- Overall Height: 1250mm (49.2 inches)
- Seat Height: 800mm (31.5 inches)
- Ground Clearance: 190mm (7.5 inches)
- Weight: 152 kg (335 lb)
- Fuel Capacity: 16.8 Litres (4.4 Gal) [including 2.7-Litre (0.7 Gal) LED-indicated reserve]
OTHER
