Honda Elite 125, CH125, Scooter, Motorcycles

1983 Elite

ENGINE
- Engine: Liquid-cooled four-stroke 124cc
DRIVETRAIN
- Transmission: V-matic^TM
- Drive: Belt
CHASSIS / SUSPENSION / BRAKES
- N/A
DIMENSION
- Wheelbase: 1200mm (47.2 in.)
- Dry weight: 102 kg (224.8 lb)
- Seat height: 760mm (29.9 in.)
OTHER
- Seat: Dual
- Accessory: Rear carrier

ENGINE
- Engine: Liquid-cooled four-stroke 124cc
- Displacement: 124cc
- Bore & Stroke: 56.5 x 49.5mm
- Compression Ratio: 10.3:1
- Fuel Delivery: 22mm CV Type
- Ignition: system: CDI
- Starting system: Electric
DRIVETRAIN
- Transmission: Variable Ratio V-matic^TM
- Drive line: Belt
- Clutch: Automatic centrifugal
- Wheels: Pressed steel
CHASSIS / SUSPENSION / BRAKES
- Front Suspension: Bottom-link type
- Rear Suspension: Twin hydraulic shocks
- Brakes: Front and rear drums
- Tire size: 3.50-10 (front and rear)
DIMENSION
- Wheelbase: 1200mm (47.2 in.)
- Dry weight: 102 kg (224.8 lb)
- Overall length: 1940mm (76.4 in.)
- Overall width: 655mm (25.8 in.)
- Seat: Dual
- Seat height: 760mm (29.9 in.)
- Fuel capacity: 8.3 liters (2.2 US gal.) (1.8 Imp. gal.)
OTHER
- Accessory: Rear carrier
- Colors:
  - Light Copper Metallic
  - Candy Ruby Red
