Honda CRF70F Motorcycles

2004 CRF70F

ENGINE
- Engine Type: 72cc air-cooled single-cylinder four-stroke
- Bore and Stroke: 47.0mm x 41.4mm
- Compression Ratio: 9.0:1
- Valve Train: : SOHC; two-valve
- Carburetion: 13.0mm piston-valve
- Ignition: CDI
- Spark plug: CR6HSA
- Plug gap: .028
DRIVETRAIN
- Transmission: Three-speed with automatic clutch
- Final Drive: #420 chain; 15T/36T
CHASSIS / SUSPENSION / BRAKES
- Front Suspension: 27.0mm telescopic fork; 3.2-inch travel
- Rear Suspension: Single-shock; 3.5-inch travel
- Front Brake: Drum
- Rear Brake: Drum
- Front Tire: 2.50-14
- Rear Tire: 3.00-12
DIMENSION
- Rake: 27.03 degrees
- Trail: 61.5mm (2.4 inches)
- Wheelbase: 42.0 inches
- Seat Height: 26.1 inches
- Ground Clearance: 7.0 inches
- Dry Weight: 128.0 pounds
- Fuel Capacity: 1.5 gallons, including 0.3-gallon reserve
OTHER
- Colors: Red
- Warranty: 6 months

ENGINE
- Engine Type: 72cc air-cooled single-cylinder four-stroke
- Bore and Stroke: 47.0mm x 41.4mm
- Compression Ratio: 9.0:1
- Valve Train: : SOHC; two-valve
- Carburetion: 13.0mm piston-valve
- Ignition: CD
- Spark plug: CR6HSA
- Plug gap: .028
DRIVETRAIN
- Transmission: Three-speed with automatic clutch
- Final Drive: #420 chain; 15T/36T
CHASSIS / SUSPENSION / BRAKES
- Front Suspension: 27.0mm telescopic fork; 3.2-inch travel
- Rear Suspension: Single-shock; 3.5-inch travel
- Front Brake: Drum
- Rear Brake: Drum
- Front Tire: 2.50-14
- Rear Tire: 3.00-12
DIMENSION
- Rake: 27.03 degrees
- Trail: 61.5mm (2.4 inches)
- Wheelbase: 42.0 inches
- Seat Height: 26.1 inches
- Ground Clearance: 7.0 inches
- Dry Weight: 128.0 pounds
- Fuel Capacity: 1.5 gallons, including 0.3-gallon reserve
OTHER
- Colors: Red
- Model ID: CRF70F
- Warranty: 6 months

ENGINE
- Engine Type: 72cc air-cooled single-cylinder four-stroke
- Bore and Stroke: 47.0mm x 41.4mm
- Compression Ratio: 9.0:1
- Valve Train: : SOHC; two-valve
- Carburetion: 13.0mm piston-valve
- Ignition: CD
- Spark plug: CR6HSA
- Plug gap: .028
DRIVETRAIN
- Transmission: Three-speed with automatic clutch
- Final Drive: #420 chain; 15T/36T
CHASSIS / SUSPENSION / BRAKES
- Front Suspension: 27.0mm telescopic fork; 3.2-inch travel
- Rear Suspension: Single-shock; 3.5-inch travel
- Front Brake: Drum
- Rear Brake: Drum
- Front Tire: 2.50-14
- Rear Tire: 3.00-12
DIMENSION
- Rake: 27.03 degrees
- Trail: 61.5mm (2.4 inches)
- Wheelbase: 42.0 inches
- Seat Height: 26.1 inches
- Ground Clearance: 7.0 inches
- Dry Weight: 128.0 pounds
- Fuel Capacity: 1.5 gallons, including 0.3-gallon reserve
OTHER
- Colors: Red
- Model ID: CRF70F

ENGINE
- Engine Type: 72cc air-cooled single-cylinder four-stroke
- Bore and Stroke: 47.0mm x 41.4mm
- Compression Ratio: 9.0:1
- Valve Train: : SOHC; two-valve
- Carburetion: 13.0mm piston-valve
- Ignition: CD
- Spark plug: CR6HSA
- Plug gap: .028
DRIVETRAIN
- Transmission: Three-speed with automatic clutch
- Final Drive: #420 chain; 15T/36T
CHASSIS / SUSPENSION / BRAKES
- Front Suspension: 27.0mm telescopic fork; 3.2-inch travel
- Rear Suspension: Single-shock; 3.5-inch travel
- Front Brake: Drum
- Rear Brake: Drum
- Front Tire: 2.50-14
- Rear Tire: 3.00-12
DIMENSION
- Rake: 27.03 degrees
- Trail: 61.5mm (2.4 inches)
- Wheelbase: 42.0 inches
- Seat Height: 26.1 inches
- Ground Clearance: 7.0 inches
- Dry Weight: 128.0 pounds
- Fuel Capacity: 1.5 gallons, including 0.3-gallon reserve
OTHER
- Colors: Red
- Model ID: CRF70F

OVERVIEW
- Think of the CRF70F as the perfect stepping stone between its bigger siblings and the CRF50F. Your youngster a tad too big for the 50F, but not quite ready for the CRF80F or 100F? No worries. This bike features the same smooth three-speed semi-automatic transmission (no clutch to deal with) and novice-friendly four-stroke power as its little brother, only in a slightly bigger package. What could be more fun than that?
ENGINE
- Engine: Type72cc air-cooled single-cylinder four-stroke
- Bore and Stroke: 47.0mm x 41.4mm
- Compression Ratio: 9.0:1
- Valve Train: : SOHC; two-valve
- Induction: 13mm piston-valve carburator
- Ignition: CD
- Spark plug: CR6HSA
- Plug gap: .028
DRIVETRAIN
- Transmission: Three-speed with automatic clutch
- Final Drive: #420 chain; 15T/36T
CHASSIS / SUSPENSION / BRAKES
- Front Suspension: 27.0mm telescopic fork; 3.2-inch travel
- Rear Suspension: Single-shock; 3.5-inch travel
- Front Brake: Drum
- Rear Brake: Drum
- Front Tire: 2.50-14
- Rear Tire: 3.00-12
DIMENSION
- Rake: 27.03 degrees
- Trail: 61.5mm (2.4 inches)
- Wheelbase: 42.0 inches
- Seat Height: 26.1 inches
- Ground Clearance: 7.0 inches
- Curb Weight: N/A
- Fuel Capacity: 1.3 gallons, including 0.3-gallon reserve
OTHER
- Emissions: Meets current CARB and EPA standards.
- Colors: Red
- Model ID: CRF70F
- 6 months Warranty: Coverage of defects in materials and workmanship

ENGINE
- Engine Size: 72cc
- Engine Detail: air-cooled single-cylinder four-stroke
- Bore Stroke: 47.0mm x 41.4mm
- Compression Ratio: 9.0:1
- Fuel System: 13mm piston-valve carburator
- Ignition: CD
DRIVETRAIN
- Transmission: Three-speed with automatic clutch
- Final Drive: #420 chain; 15T/36T
CHASSIS / SUSPENSION / BRAKES
- Suspension Front: 27.0mm telescopic fork; 3.2-inch travel
- Suspension Rear: Single-shock; 3.5-inch travel
- Brakes Front: Drum
- Brakes Rear: Drum
- Tire Front: 2.50-14
- Tire Rear: 3.00-12
DIMENSION
- Wheelbase: 42 in.
- Seat Height: 26.1 in.
- Curb Weight: 139 lbs.
- Fuel Capacity: 1.3 gal.
OTHER
- Colors: Red
- Price: $1699
- Warranty: 6 Months
