Honda Spree 50 (NQ50) Motorcycles

1984 SPREE 50 NQ50

ENGINE
- Engine type: Forced-air-cooled two-stroke single cylinder
- Oiler: automatic oil injection
- Displacement: 49cc
- Bore & Stroke: 41 x 37.4mm
- Compression ratio: 7.2:1
- Spark plug: BPR6HS
- Plug gap: .028
- Fuel Delivery: 14mm piston-valve type
- Starter: Electric
DRIVETRAIN
- Transmission: Single-speed
- Clutch: automatic centrifugal
- Drive line: Belt primary drive with gear final drive
CHASSIS / SUSPENSION / BRAKES
- Brakes: Front and Rear drum
- Front suspension: Telescopic fork
- Rear suspension: Single shock
- Tire size: 2.50-10 front and rear
- Wheels: pressed steel
DIMENSION
- Wheelbase: 1065mm (41.9 in.)
- Dry weight: 38.8 kg (85.5 lb)
- Overall length: 1490mm (58.6 in.)
- Overall width: 590mm (23.2 in.)
- Seat height: 693mm (27.3 in.)
- Fuel capacity: 2.5 liter (.66 US gal.) (.55 Imp. gal.)
OTHER
- Accessory: Rear carrier
- Colors:
  - Cortina White with red "Spree" logo
  - Sparkling Red with white "Spree" logo
  - Vista blue with white "Spree" logo
- V.I.N.: JH2AF060XES000004
- Engine: AF05E-2000005

ENGINE
- Engine: Forced-air-cooled two-stroke single cylinder
- Displacement: 49cc
- Bore & Stroke: 41 x 37.4mm
- Compression ratio: 7.2:1
- Spark plug: BPR6HS
- Plug gap: .028
- Oiler: automatic oil injection
- Fuel Delivery: 14mm Piston-valve type
- Starter: Electric
DRIVETRAIN
- Transmission: Single-speed
- Clutch: automatic centrifugal
- Drive line: Belt primary drive with gear final drive
CHASSIS / SUSPENSION / BRAKES
- Brakes: Front and rear drum
- Front suspension: Telescopic fork
- Rear suspension: Single shock
- Tire size: 2.50-10 front and rear
- Wheels: Pressed steel
DIMENSION
- Wheelbase: 1065mm (41.9 in.)
- Dry weight: 39 kg (85.9 lb)
- Overall length: 1530mm (60.2 in.)
- Overall width: 590mm (23.2 in.)
- Seat height: 710mm (27.9 in.)
- Fuel capacity: 2.5 liters (.66 US gal.) (.55 Imp. gal.)
OTHER
- Accessory: Rear carrier
- Colors:
  - Black with lavender "Spree" logo
  - Sparkling Red with white "Spree" logo
  - Cortina White
  - Vista Blue
- V.I.N.: JH2AF0609FS000001
- Engine: AF06E-2100001

ENGINE
- Engine: Forced-air-cooled 49cc two-stroke single cylinder with automatic oil injection
- Spark plug: BPR6HSA
- Plug gap: .028
- Starter: Electric
DRIVETRAIN
- Transmission: Single-speed with automatic clutch
CHASSIS / SUSPENSION / BRAKES
- Brakes: Front and Rear drum
- Front suspension: Telescopic fork
- Rear suspension: Single shock
- Tire size: 2.50-10 front and rear
- Wheels: pressed steel
DIMENSION
- Wheelbase: 1065mm (41.9 in.)
- Dry weight: 39 kg (86 lb)
- Seat height: 700mm (27.6 in.)
OTHER
- Accessory: Rear carrier
- Colors:
  - Black with lavender "Spree" logo and seat trim
  - Sparkling Red with white "Spree" logo
- V.I.N.: JH2AF0603GS200001
- Engine: AF05E-2200001

ENGINE
- Engine: Forced-air-cooled 49cc two-stroke single cylinder with automatic oil injection
- Spark plug: BPR6HSA
- Plug gap: .028
- Starter: Electric
DRIVETRAIN
- Transmission: Single-speed with automatic clutch
CHASSIS / SUSPENSION / BRAKES
- Brakes: Front and Rear drum
- Front suspension: Telescopic fork
- Rear suspension: Single shock
- Tire size: 2.50-10 front and rear
- Wheels: pressed steel
DIMENSION
- Wheelbase: 1065mm (41.9 in.)
- Dry weight: 39 kg (86 lb)
- Seat height: 700mm (27.6 in.)
OTHER
- Accessory: Rear carrier
- Colors:
  - Black with lavender "Spree" logo and seat trim
  - Sparkling Red with white "Spree" logo and red seat trim
  - Kriti Blue with pink "Spree" logo and seat trim
- Front storage compartment
- V.I.N.: JH2AF0603GS200001
- Engine: AF05E-2200001
