Three versions of the CTS were available, each with an armload of standard features
Wheelbase | 113.4" |
Overall length | 191.6" |
Overall width | 72.5" |
Overall height | 58" |
Front Tread | 62" |
Rear Tread | 62" |
Curb Weight | 3,861 to 3,874 lb |
Seating Capacity | Five |
Interior Volume | 98 cu. ft. |
Trunk Volume | 13.6 cu. ft. |
Fuel Tank | 17 gal. US |
Feature | Front | Rear |
Head room | 38.8" | 37.2" |
Hip room | 55.1" | 54.1" |
Leg room | 42.4" | 35.9" |
Shoulderg room | 56.6" | 56.2" |
Type | V6 VVT | Direct Injection V6 | Supercharged V8 |
Block | Cast aluminum | ||
Displacement | 3.6 Liters | 3.6 Liters | 6.2 Liters |
Bore & Stroke | 103mm x 92mm | ||
Horsepower | 263 hp @ 6400 rpm | 304 hp @ 6400 rpm | 556 @ 6100 rpm |
Torque | 253 lb-ft @ 3100 rpm | 273 lb-ft @ 5200 rpm | 551 lb-ft @ 3800 rpm |
Camshaft | Hydraulic roller-type, low lift | ||
Compression Ratio | 9.1:1 nominal | ||
Connecting Rods | Powder metal | ||
Crankshaft | Steel, 8-bolt flange | ||
Cylinder Head | Cast aluminum | ||
Firing Order | 1-8-7-2-6-5-4-3 | ||
Fuel System | Sequential fuel injection | ||
Ignition System | Direct-mount ignition coils; extended-life dual platinum-tipped spark plugs | ||
Valvetrain | Overhead valve, 2 valves per cylinder; 12.5 mm lift | ||
Added Engine features | Pan-mounted oil cooler Cast pistons High-flow cylinder heads Block-mounted piston squirters Close-mounted converters Acoustic engine cover E67 engine controller |
Feature | CTS 3.6L V6 & CTS 3.6L DI | CTS-V |
Drive System | Rear-Wheel Drive | Performance rear-wheel-drive system |
Optional Drive System | All-Wheel Drive | |
Standard Transmission | Manual 6-speed transmission | 6-speed, rear-wheel drive, TREMEC(R) TR-6060 manual |
Manual Transmission Gear Ratio | 1st: 2.66; 2nd: 1.78; 3rd: 1.30; 4th: 1.00; 5th: 0.80; 6th: 0.63; Reverse: 2.90; Final Drive: 3.73 | |
Optional transmission | 6-speed automatic (standard on 3.6L Direct Injection V6 model) | 6-speed, rear-wheel drive, electronically controlled, automatic overdrive transmission with torque converter clutch, Performance Algorithm Shifting and Driver Shift Control (DSC) for clutchless manual operation, includes steering wheel mounted paddle shifters |
Automatic Transmission Gear Ratio | 1st: 4.02; 2nd: 2.36; 3rd: 1.53; 4th: 1.15; 5th: 0.85; 6th: 0.67; Reverse: 3.06; Final Drive: 3.23 | |
Fuel Tank | 17 gal US | |
Towing Capacity | 1,000 lb | |
Standard Brakes | 4-wheel disc brakes with anti-lock system | High-performance aluminum 6-piston front, 4-piston rear caliper Brembo disc brakes with vented 14.57" rotors front, 14.37" rotors rear; Power-assist with 4-channel ABS |
Optional AWD Brakes | 18" performance brake system | |
Suspension | 4-wheel independent design that utilizes a short/long arm, coil-over strut with anti-sway bar in front, and an independent, modified multi-link with anti-sway bar in the rear; both benefit from coil-over monotube dampers | Front: Independent, short/long arm; 29-mm hollow stabilizer bar; elastomeric handling bushing; hydraulic ride bushing; 65-N/mm spring rate Rear: Independent, multilink; 25.4-mm hollow stabilizer bar; elastomeric trailing arm bushings; 90-N/mm spring rate |
Optional Suspension | Sport Performance Suspension System with rear load leveling and power, speed-sensitive variable assist steering | |
Traction Control | All-speed traction control with brake and engine intervention | All-speed with brake and engine intervention |
Steering | ZF Servtronic(R) II power rack-and-pinion | ZF Servotronic 2(R), power rack-and-pinion |
Construction | Ultra-strong frame armed with high-strength steel | |
Standard Tires | All-season P235/55R17 H-rated (130 mph at 30 psi) tires | Front: P255/40ZR19 Michelin Pilot Sport 2 Rear: P285/35ZR19 Michelin Pilot Sport 2 |
Optional Tires | All-season P235/50R18 V-rated tires (Available with Performance Collection; Standard on Premium Collection) | |
Optional Tires | All-season P235/50ZR18 Y-rated tires (Available only with 18-inch Summer Tire Performance Package) | |
Standard Wheels | 17" x 8" cast aluminum wheels with painted finish | Front: 19" x 9", Rear: 19" x 9.5" aluminum alloy 5-lug with 10-spoke, painted |
Optional Wheels | 17" x 8" cast aluminum wheels with machined bright finish (Available with Luxury Collection) | Front: 19" x 9", Rear: 19" x 9.5" aluminum alloy 5-lug with 10-spoke, polished |
Optional Wheels | 18" x 8" cast aluminum wheels with premium, multi-coat painted finish (Available with Performance Collection) | |
Optional Wheels | 18" x 8" cast aluminum wheels with high polished finish (Available in the Performance or Premium Collections; Standard with 18-inch Summer Tire Performance Package) | |
Stability Control System | StabiliTrak, 4-channel, computer controlled, 4 driver-selectable modes | |
Weight Distribution | 54/46 front/rear | |
Limited-Slip Differential | With axle positraction |
Model | City | Highway |
RWD 3.6L Auto model | 18 MPG | 26 MPG |
RWD 3.6L Manual model | 16 MPG | 25 MPG |
AWD 3.6L Auto model | 17 MPG | 26 MPG |
RWD 3.6L DI Auto model | 17 MPG | 26 MPG |
RWD 3.6L DI Manual model | 16 MPG | 25 MPG |
AWD 3.6L DI Auto model | 17 MPG | 26 MPG |
